BMW X5: ENGINES &
TECHNICAL DATA.
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW X5.
TECHNICAL DATA OF THE BMW X5.
- BMW X5 xDrive40i
- BMW X5 M50i
- BMW X5 xDrive25d
- BMW X5 xDrive30d
- BMW X5 xDrive40d
No search result found. Please try another input
Powertrain type | Petrol |
---|---|
Power in kW (hp) | 245 (333) |
Torque in Nm | 450 |
Transmission | 8-speed, automatic |
Drivetrain | All-wheel drive |
Cylinders | 6 |
---|---|
Displacement in cm3 | 2998 |
Nominal power in kW (hp)/1/min | 245 (333)/5500-6250 |
Nominal torque in Nm/1/min | 450/1600-4800 |
(Nominal) power/30 minutes power in kW (hp) | 8 (11)/- [10] |
---|---|
(Nominal) torque in Nm | - [10] |
Acceleration 0–100 km/h in s | 5.7 |
---|---|
Maximum speed in km/h | 243 |
Electric top speed in km/h | - |
Fuel consumption, combined in l/100 km [5] | 10.7-8.9 |
---|---|
CO2 emissions, combined WLTP in g/km [5] | 244-204 |
Energy consumption, combined WLTP in kWh/100 km [5] | - |
Electric range, WLTP in km [6] | - |
Battery capacity in kWh | 0.46 |
---|---|
Maximum charging power AC/DC in kW | - |
Charging time DC 10–80% in min | - |
Charging time AC 0–100% in h | - |
Length/width/height in mm | 4922/2004/1745 |
---|---|
Wheelbase in mm | 2975 |
Curb weight in kg [8] | - [10] |
Luggage capacity in l | 650-1870 |
Fuel capacity in l | 83 |
Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg | - [10]/- [10] |
Powertrain type | Petrol |
---|---|
Power in kW (hp) | - [10] |
Torque in Nm | - [10] |
Transmission | 8-speed, automatic |
Drivetrain | All-wheel drive |
Cylinders | 8 |
---|---|
Displacement in cm3 | 4395 |
Nominal power in kW (hp)/1/min | 390 (530)/5500-6000 |
Nominal torque in Nm/1/min | 750/1800-4600 |
(Nominal) power/30 minutes power in kW (hp) | - |
---|---|
(Nominal) torque in Nm | - |
Acceleration 0–100 km/h in s | 4.3 |
---|---|
Maximum speed in km/h | 250 |
Electric top speed in km/h | - |
Fuel consumption, combined in l/100 km [5] | 12.4-11.6 |
---|---|
CO2 emissions, combined WLTP in g/km [5] | 283-266 |
Energy consumption, combined WLTP in kWh/100 km [5] | - |
Electric range, WLTP in km [6] | - |
Battery capacity in kWh | - |
---|---|
Maximum charging power AC/DC in kW | - |
Charging time DC 10–80% in min | - |
Charging time AC 0–100% in h | - |
Length/width/height in mm | 4922/2004/1745 |
---|---|
Wheelbase in mm | 2975 |
Curb weight in kg [8] | 2335 |
Luggage capacity in l | 650-1870 |
Fuel capacity in l | 83 |
Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg | 3500/140 |
Powertrain type | Diesel |
---|---|
Power in kW (hp) | 170 (231) |
Torque in Nm | 450 |
Transmission | 8-speed, automatic |
Drivetrain | All-wheel drive |
Cylinders | 4 |
---|---|
Displacement in cm3 | 1995 |
Nominal power in kW (hp)/1/min | 170 (231)/4400 |
Nominal torque in Nm/1/min | 450/1500-3000 |
(Nominal) power/30 minutes power in kW (hp) | - |
---|---|
(Nominal) torque in Nm | - |
Acceleration 0–100 km/h in s | 7.5 |
---|---|
Maximum speed in km/h | 222 |
Electric top speed in km/h | - |
Fuel consumption, combined in l/100 km [5] | 8.5-7.1 |
---|---|
CO2 emissions, combined WLTP in g/km [5] | 222-187 |
Energy consumption, combined WLTP in kWh/100 km [5] | - |
Electric range, WLTP in km [6] | - |
Battery capacity in kWh | - |
---|---|
Maximum charging power AC/DC in kW | - |
Charging time DC 10–80% in min | - |
Charging time AC 0–100% in h | - |
Length/width/height in mm | 4922/2004/1745 |
---|---|
Wheelbase in mm | 2975 |
Curb weight in kg [8] | 2145 |
Luggage capacity in l | 650-1870 |
Fuel capacity in l | 80 |
Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg | 2700/140 |
Powertrain type | Diesel |
---|---|
Power in kW (hp) | 210 (286) |
Torque in Nm | 650 |
Transmission | 8-speed, automatic |
Drivetrain | All-wheel drive |
Cylinders | 6 |
---|---|
Displacement in cm3 | 2993 |
Nominal power in kW (hp)/1/min | 210 (286)/4000 |
Nominal torque in Nm/1/min | 650/1500-2500 |
(Nominal) power/30 minutes power in kW (hp) | 8 (11)/- [10] |
---|---|
(Nominal) torque in Nm | - [10] |
Acceleration 0–100 km/h in s | 6.1 |
---|---|
Maximum speed in km/h | 235 |
Electric top speed in km/h | - |
Fuel consumption, combined in l/100 km [5] | 8.0-6.6 |
---|---|
CO2 emissions, combined WLTP in g/km [5] | 210-173 |
Energy consumption, combined WLTP in kWh/100 km [5] | - |
Electric range, WLTP in km [6] | - |
Battery capacity in kWh | 0.46 |
---|---|
Maximum charging power AC/DC in kW | - |
Charging time DC 10–80% in min | - |
Charging time AC 0–100% in h | - |
Length/width/height in mm | 4922/2004/1745 |
---|---|
Wheelbase in mm | 2975 |
Curb weight in kg [8] | 2265 |
Luggage capacity in l | 650-1870 |
Fuel capacity in l | 80 |
Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg | 3500/140 |
Powertrain type | Diesel |
---|---|
Power in kW (hp) | 250 (340) |
Torque in Nm | 700 |
Transmission | 8-speed, automatic |
Drivetrain | All-wheel drive |
Cylinders | 6 |
---|---|
Displacement in cm3 | 2993 |
Nominal power in kW (hp)/1/min | 250 (340)/4400 |
Nominal torque in Nm/1/min | 700/1750-2250 |
(Nominal) power/30 minutes power in kW (hp) | 8 (11)/- [10] |
---|---|
(Nominal) torque in Nm | 25 |
Acceleration 0–100 km/h in s | 5.5 |
---|---|
Maximum speed in km/h | 245 |
Electric top speed in km/h | - |
Fuel consumption, combined in l/100 km [5] | 8.1-6.9 |
---|---|
CO2 emissions, combined WLTP in g/km [5] | 213-180 |
Energy consumption, combined WLTP in kWh/100 km [5] | - |
Electric range, WLTP in km [6] | - |
Battery capacity in kWh | - |
---|---|
Maximum charging power AC/DC in kW | - |
Charging time DC 10–80% in min | - |
Charging time AC 0–100% in h | - |
Length/width/height in mm | 4922/2004/1745 |
---|---|
Wheelbase in mm | 2975 |
Curb weight in kg [8] | 2275 |
Luggage capacity in l | 650-1870 |
Fuel capacity in l | 80 |
Optionally delivered with support for trailer load, braked, up to 12%/towbar download in kg | 3500/140 |
(1) Only with factory-fitted trailer tow hitch.
Fuel consumption, electricity consumption and CO2 emissions of the BMW X5.
BMW X5 xDrive40i:
Fuel consumption in l/100 km (combined): 10.7–8.9
CO2 emissions in g/km (combined): 244–204
BMW X5 xDrive45e:
Fuel consumption in l/100 km (combined): 1.7–1.2
CO2 emissions in g/km (combined): 40–27
Electricity consumption combined in kWh/100 km: 27.7–24.3
Official data on fuel consumption, CO2 emissions, power consumption and electric range were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp.
For more information on the official fuel consumption and official specific CO2 emissions of new passenger cars, see the ‘Guide to Fuel Consumption, CO2 Emissions, and Electricity Consumption of New Passenger Cars’, which is available free of charge at all sales outlets, from Deutsche AutomobilTreuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern- Scharnhausen, and at www.dat.de/co2
Fuel consumption, electricity consumption and CO2 emissions of the BMW X5.
BMW X5 xDrive40i:
Fuel consumption in l/100 km (combined): 10.7–8.9
CO2 emissions in g/km (combined): 244–204The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.
The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.
For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html
The figures for performance, consumption and CO2 emissions refer to vehicles with standard transmission.
[1]Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.
[2]For plug-in hybrid: Electric drive depending on battery charging level.
[3]For plug-in hybrid: At temperatures below freezing, the fully electric drive system is only available after a few kilometres of driving, once the battery has heated to operational temperature.
[4]Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp
[5]For plug-in hybrid: Weighted, combined (EC AC Charge Weighted)
[6]Range depends on various factors, in particular: individual driving style, route characteristics, outside temperature, heating/air conditioning, pre-conditioning.
[7]The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.[8]The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.
[9] Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value).
[10]Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value). Electric drive depending on battery charging level.
[11]Provisional figures; any missing figures were unavailable at the time of publication.
