    BMW X1: TECHNICAL DATA.

    Weight

    Unladen weight EU in kg 1,480 [1,510]
    Max. permissible weight in kg 2,000 [2,025]
    Permitted load in kg 595 [590]
    Permitted axle load front/rear in kg 995/1,035 [1,020/1,035]
    Luggage capacity min. (seats up or roof down) in l 505 [505]
    Luggage capacity max. (seats down or roof up) in l 1,550 [1,550]
    Trailer load (unbraked) in kg 740 [750]
    Trailer load 8% (braked) in kg 1,700 [1,700]
    Trailer load 12% (braked) in kg 1,700 [1,700]

    Engine

    Cylinders/valves 3/4
    Capacity in ccm 1,499
    Stroke/bore in mm 94.6/82.0
    Engine power* in kW (hp) at 1/min 100 (136)/4,500-6,500
    Engine torque (Nm) at 1/min 220/1,500-4,100
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 205 [203]
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 9.7 [9.7]

    Fuel consumption

    Combined in l/100 km 7.2-6.1
    CO2 combined emissions in g/km 163-139
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 51

    Wheels

    Tyre dimensions front 225/55 R17 97 W
    Tyre dimensions rear 225/55 R17 97 W
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (hp) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (hp) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,655
    Max. permissible weight in kg 2.155
    Permitted load in kg 575
    Permitted axle load front/rear in kg 1,090/1,100
    Luggage capacity min. (seats up or roof down) in l 505
    Luggage capacity max. (seats down or roof up) in l 1,550
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 2,000
    Trailer load 12% (braked) in kg 2,000

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power* in kW (hp) at 1/min 131 (178)/5,000-5,500
    Engine torque (Nm) at 1/min 280/1,350-4,200
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 223
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 7.3

    Fuel consumption

    Combined in l/100 km 7.7-6.9
    CO2 combined emissions in g/km 175-158
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 61

    Wheels

    Tyre dimensions front 225/55 R17 97 W
    Tyre dimensions rear 225/55 R17 97 W
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (hp) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (hp) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,570
    Max. permissible weight in kg 2.065
    Permitted load in kg 570
    Permitted axle load front/rear in kg 1,050/1,050
    Luggage capacity min. (seats up or roof down) in l 505
    Luggage capacity max. (seats down or roof up) in l 1,550
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power* in kW (hp) at 1/min 131 (178)/5,000-5,500
    Engine torque (Nm) at 1/min 280/1,350-4,200
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 226
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 7.6

    Fuel consumption

    Combined in l/100 km 7.3-6.5
    CO2 combined emissions in g/km 165-147
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 51

    Wheels

    Tyre dimensions front 225/55 R17 97 W
    Tyre dimensions rear 225/55 R17 97 W
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (hp) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (hp) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,555 [1,575]
    Max. permissible weight in kg 2,040 [2,040]
    Permitted load in kg 560 [540]
    Permitted axle load front/rear in kg 1,035/1,070 [1,065/1,070]
    Luggage capacity min. (seats up or roof down) in l 505 [505]
    Luggage capacity max. (seats down or roof up) in l 1,550 [1,550]
    Trailer load (unbraked) in kg 750 [750]
    Trailer load 8% (braked) in kg 1,700 [1,700]
    Trailer load 12% (braked) in kg 1,700 [1,700]

    Engine

    Cylinders/valves 3/4
    Capacity in ccm 1,496
    Stroke/bore in mm 90.0/84.0
    Engine power* in kW (hp) at 1/min 85 (116)/4,000
    Engine torque (Nm) at 1/min 270/1,750-2,250
    Compression ratio : 1 16.5

    Performance

    Top speed in km/h 190 [190]
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 11.5 [11.5]

    Fuel consumption

    Combined in l/100 km 5.7-5.1
    CO2 combined emissions in g/km 150-132
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 51

    Wheels

    Tyre dimensions front 225/55 R17 97 W
    Tyre dimensions rear 225/55 R17 97 W
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (hp) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (hp) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,585 [1,615]
    Max. permissible weight in kg 2,090 [2,125]
    Permitted load in kg 580 [588]
    Permitted axle load front/rear in kg 1,055/1,070 [1,095/1,070]
    Luggage capacity min. (seats up or roof down) in l 505 [505]
    Luggage capacity max. (seats down or roof up) in l 1,550 [1,550]
    Trailer load (unbraked) in kg 750 [750]
    Trailer load 8% (braked) in kg 1,800 [1,800]
    Trailer load 12% (braked) in kg 1,800 [1,800]

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,995
    Stroke/bore in mm 90.0/84.0
    Engine power* in kW (hp) at 1/min 100-110 (136-150)/4,000
    Engine torque (Nm) at 1/min 350/1,750-2,500
    Compression ratio : 1 16.5

    Performance

    Top speed in km/h 200-205 [200-205]
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 10.0-9.3 [10.1-9.4]

    Fuel consumption

    Combined in l/100 km 5.8-4.9
    CO2 combined emissions in g/km 151-128
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 51

    Wheels

    Tyre dimensions front 225/55 R17 97 W
    Tyre dimensions rear 225/55 R17 97 W
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (hp) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (hp) -
    Combined torque Nm

    Weight

    Unladen weight EU in kg 1.685
    Max. permissible weight in kg 2,190
    Permitted load in kg 580
    Permitted axle load front/rear in kg 1,115/1,110
    Luggage capacity min. (seats up or roof down) in l 505
    Luggage capacity max. (seats down or roof up) in l 1,550
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,995
    Stroke/bore in mm 90.0/84.0
    Engine power* in kW (hp) at 1/min 100-110 (136-150)/4,000
    Engine torque (Nm) at 1/min 350/1,750-2,500
    Compression ratio : 1 16.5

    Performance

    Top speed in km/h 197-204
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 10.2-9.4

    Fuel consumption

    Combined in l/100 km 6.1-5.4
    CO2 combined emissions in g/km 159-142
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 51

    Wheels

    Tyre dimensions front 225/55 R17 97 W
    Tyre dimensions rear 225/55 R17 97 W
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (hp) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (hp) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,630
    Max. permissible weight in kg 2,130
    Permitted load in kg 575
    Permitted axle load front/rear in kg 1,095/1,080
    Luggage capacity min. (seats up or roof down) in l 505
    Luggage capacity max. (seats down or roof up) in l 1,550
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,995
    Stroke/bore in mm 90.0/84.0
    Engine power* in kW (hp) at 1/min 140 (190)/4,000
    Engine torque (Nm) at 1/min 400/1,750-2,500
    Compression ratio : 1 16.5

    Performance

    Top speed in km/h 222
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 7,9

    Fuel consumption

    Combined in l/100 km 5.8-5.2
    CO2 combined emissions in g/km 152-136
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 51

    Wheels

    Tyre dimensions front 225/55 R17 97 W
    Tyre dimensions rear 225/55 R17 97 W
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (hp) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (hp) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,695
    Max. permissible weight in kg 2,200
    Permitted load in kg 580
    Permitted axle load front/rear in kg 1,115/1,120
    Luggage capacity min. (seats up or roof down) in l 505
    Luggage capacity max. (seats down or roof up) in l 1,550
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 2,000
    Trailer load 12% (braked) in kg 2,000

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,995
    Stroke/bore in mm 90.0/84.0
    Engine power* in kW (hp) at 1/min 120-140 (163-190)/4,000
    Engine torque (Nm) at 1/min 400/1,750-2,500
    Compression ratio : 1 16.5

    Performance

    Top speed in km/h 211-219
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 8.7-7.8

    Fuel consumption

    Combined in l/100 km 6.3-5.4
    CO2 combined emissions in g/km 164-142
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 51

    Wheels

    Tyre dimensions front 225/55 R17 97 W
    Tyre dimensions rear 225/55 R17 97 W
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (hp) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (hp) -
    Combined torque Nm -

    Weight

    Unladen weight EU in kg 1,695
    Max. permissible weight in kg 2,180
    Permitted load in kg 560
    Permitted axle load front/rear in kg 1,125/1,095
    Luggage capacity min. (seats up or roof down) in l 505
    Luggage capacity max. (seats down or roof up) in l 1,550
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 2,000
    Trailer load 12% (braked) in kg 2,000

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,995
    Stroke/bore in mm 90.0/84.0
    Engine power* in kW (hp) at 1/min 170 (231)/4,400
    Engine torque (Nm) at 1/min 450/1,500-3,000
    Compression ratio : 1 16.5

    Performance

    Top speed in km/h 235
    Top speed electrical in km/h -
    Acceleration 0–100 km/h in s 6.6

    Fuel consumption

    Combined in l/100 km 6.3-5.7
    CO2 combined emissions in g/km 166-149
    Electricity consumption, combined in kWh/100km -
    Tank capacity, approx. in l 51

    Wheels

    Tyre dimensions front 225/55 R17 97 W
    Tyre dimensions rear 225/55 R17 97 W
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Range and charging

    Electric range in km -
    Growth capacity of lithium-ion battery in kWh -
    Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
    Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

    Electric engine

    Electric engine power kW (hp) at 1/min -
    Electric Engine torque (Nm) at 1/min -

    Combined system power

    Combined power kW (hp) -
    Combined torque Nm -

    FUEL CONSUMPTION AND CO2 EMISSIONS.

    BMW X1 xDRIVE20i:
    Fuel consumption in l/100 km (combined): 7.7–6.9
    CO2 emissions in g/km (combined): 175–158

    BMW X1 xDrive25e**:
    Fuel consumption in l/100 km (combined): 1.9–1.7
    CO2 emissions in g/km (combined): 44–39
    Energy consumption in kWh/100 km (combined): 19.6–19.2


    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp


    ** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.

    Read more

    Fuel consumption and CO2 emissions.

    • BMW X1 xDrive20i:
      Fuel consumption in l/100 km (combined): 7.7-6.9
      CO2 emissions in g/km (combined): 175-158

      The information on fuel consumption, CO2 emissions and energy consumption has been determined in accordance with the prescribed measurement procedure VO (EU) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

      Further information about the official fuel consumption and the official specific CO2 emissions for new passenger automobiles can be found in the 'New Passenger Vehicle Fuel Consumption and CO2 Emission Guidelines', which are available free of charge at all sales outlets and from DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Str. 1, 73760 Ostfildern, Germany and on https://www.dat.de/co2

      The values are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. For vehicle related taxes or other duties based (at least inter alia) on CO2-emissions the CO2 values may differ to the values stated here.
