THE ALL-NEW BMW 4 SERIES GRAN COUPÉ: ENGINES & TECHNICAL DATA
The key facts and figures on the new BMW 4 Series Gran Coupé at a glance: engines, consumption, CO2 emissions and dimensions. Check out all the performance data such as displacement, horsepower, torque and acceleration – and find out which engine best meets your needs.
THE 4THE ALL-NEW BMW 4 SERIES GRAN COUPÉ: ENGINES & TECHNICAL DATA
The key facts and figures on the new BMW 4 Series Gran Coupé at a glance: engines, consumption, CO2 emissions and dimensions. Check out all the performance data such as displacement, horsepower, torque and acceleration – and find out which engine best meets your needs.
TECHNICAL DATA OF THE ALL-NEW BMW 4 SERIES GRAN COUPÉ.
Select model
- BMW 420i Gran Coupé
- BMW 430i Gran Coupé
- BMW M440i xDrive Gran Coupé
- BMW 420d Gran Coupé
- BMW 420d xDrive Gran Coupé
No search result found. Please try another input
_15092021/images/bmw_420i_gran_coupé/bmw-4-series-gran-coupe-technical-data-sketch.jpg/jcr:content/renditions/cq5dam.resized.img.585.low.time1621253788296.jpg)
| Unladen weight EU in kg | 1,695 |
|---|---|
| Max. permissible weight in kg | 2,175 |
| Permitted load in kg | 555 |
| Permitted axle load front/rear in kg | 1,015/1,245 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1,290 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,600 |
| Trailer load 12% (braked) in kg | 1,600 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 135 (184)/5,000-6,500 |
| Engine torque (Nm) at 1/min | 300/1,350-4,000 |
| Compression ratio : 1 | 11.0 |
| Top speed in km/h | 235 |
|---|---|
| Acceleration 0–100 km/h in s | 7.9 |
| Combined in l/100 km | 7.3-6.6 |
|---|---|
| CO2 combined emissions in g/km | 166-150 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/55 R17 101 Y XL |
|---|---|
| Tyre dimensions rear | 225/55 R17 101 Y XL |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1,720 |
|---|---|
| Max. permissible weight in kg | 2,200 |
| Permitted load in kg | 555 |
| Permitted axle load front/rear in kg | 1,025/1,255 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1,290 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,600 |
| Trailer load 12% (braked) in kg | 1,600 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 180 (245)/4,500-6,500 |
| Engine torque (Nm) at 1/min | 400/1,600-4,000 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 6.2 |
| Combined in l/100 km | 7.6-6.8 |
|---|---|
| CO2 combined emissions in g/km | 173-156 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/55 R17 101 Y XL |
|---|---|
| Tyre dimensions rear | 225/55 R17 101 Y XL |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1,900 |
|---|---|
| Max. permissible weight in kg | 2,380 |
| Permitted load in kg | 555 |
| Permitted axle load front/rear in kg | 1,145/1,325 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1,290 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,800 |
| Trailer load 12% (braked) in kg | 1,800 |
| Cylinders/valves | 6/4 |
|---|---|
| Capacity in ccm | 2,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 275 (374)/5,500-6,500 |
| Engine torque (Nm) at 1/min | 500/1,900-5,000 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 4.7 |
| Combined in l/100 km | 8.5-8.0 |
|---|---|
| CO2 combined emissions in g/km | 194-181 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 245/45 R18 100 Y XL |
|---|---|
| Tyre dimensions rear | 245/45 R18 100 Y XL |
| Wheel dimensions and material front | 8.5 J x 18 inches, light-alloy |
| Wheel dimensions and material rear | 8.5 J x 18 inches, light-alloy |
| Unladen weight EU in kg | 1,780-1,745 |
|---|---|
| Max. permissible weight in kg | 2,260 |
| Permitted load in kg | 590-555 |
| Permitted axle load front/rear in kg | 1,060/1,310 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1,290 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,600 |
| Trailer load 12% (braked) in kg | 1,600 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,995 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power in kW (hp) at 1/min | 140 (190)/4,000 |
| Engine torque (Nm) at 1/min | 400/1,750-2,500 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 235 |
|---|---|
| Acceleration 0–100 km/h in s | 7.3 |
| Combined in l/100 km | 5.4-4.8 |
|---|---|
| CO2 combined emissions in g/km | 141-126 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/55 R17 101 Y XL |
|---|---|
| Tyre dimensions rear | 225/55 R17 101 Y XL |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1,835-1,805 |
|---|---|
| Max. permissible weight in kg | 2,315 |
| Permitted load in kg | 585-555 |
| Permitted axle load front/rear in kg | 1,105/1,315 |
| Luggage capacity min. (seats up or roof down) in l | 470 |
| Luggage capacity max. (seats down or roof up) in l | 1,290 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,600 |
| Trailer load 12% (braked) in kg | 1,600 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,995 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power in kW (hp) at 1/min | 140 (190)/4,000 |
| Engine torque (Nm) at 1/min | 400/1,750-2,500 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 238 |
|---|---|
| Acceleration 0–100 km/h in s | 7.8-7.6 |
| Combined in l/100 km | 5.7-5.1 |
|---|---|
| CO2 combined emissions in g/km | 150-122 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/55 R17 101 Y XL |
|---|---|
| Tyre dimensions rear | 225/55 R17 101 Y XL |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
Fuel consumption and CO2 emissions of the BMW 4 Series Gran Coupé.
BMW M440i xDrive Gran Coupé:
Fuel consumption in l/100 km (combined): 8.5–8.0
CO2 emissions in g/km (combined): 194–181
Official data on fuel consumption and CO2 emissions were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the NEDC take into account differences in the selected wheel and tire size; figures in the WLTP take into account any optional equipment. WLTP values are used for assessing taxes and other vehicle-related charges that are (also) based on CO2 emissions, as well as for the purposes of vehicle-specific subsidies, if applicable. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp.
Fuel consumption and CO2 emissions of the BMW 4 Series Gran Coupé.
BMW M440i xDrive Gran Coupé:
Fuel consumption in l/100 km (combined): 8.5–8.0
CO2 emissions in g/km (combined): 194–181Official data on fuel consumption and CO2 emissions were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp.
